| Product properties | Type: SC Product type: Fiber optic connector (cable side) Number of positions: 12 Number of slots: 12 Cable outlet: straight |
| Electrical properties | Attenuation: ââ°¤ 0.3 dB (1310Ãnm) Transmission medium: FO Transmission speed: 100 GBit/s |
| Dimensions | Width: 9 mm Height: 8.3 mm Length: 2500 mm Mechanical characteristics Ferrule diameter: 2.50 mm |
| Material specifications | Color: blue Color of the housing part: blue Flammability rating according to UL 94: V0 Ferrule material: Zirconia ceramics Material of grip body: blue Housing material: Plastic Outer sheath, material: LSZH |
| Connector | Connection 1 Type: Plug SC duplex Degree of protection: IP20 Connection 2 Type: free cable end free cable end Degree of protection: IP20 |
| Cable/line | Cable length: 2.50 m Cable type: Optical wire 900Ãõm Cable structure: semi-loose compact wires (STB) Outer sheath, material: LSZH Single wire, material: LSZH Individual wire diameter: 900 õm Tensile strength short-term/long-term: 10 N Whip length: 2500 mm Halogen-free: yes Resistance to oil: no Flame resistance: yes FO cable Number of fibers: 12 Fiber: 9/125Ãõm Fiber type: Singlemode Attenuation: ââ°¤ 0.3 dB Return Loss: ââ°¥ 50 dB Transmission medium: Single-mode fiberglass |
| Mechanical properties | Tensile strength short-term/long-term: 10 N Mechanical data Insertion/withdrawal cycles: > 500 Smallest bending radius: 30 mm |
| Characteristics | Attenuation: ââ°¤ 0.3 dB (1310Ãnm) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -40°C ... 85°C Ambient temperature (assembly): 0°C ... 50°C Resistance to oil: no |
| Standards and regulations | Flame resistance: yes Resistance to oil: no |
| Mounting | Connection method: SC |
