| Product properties | Type: SPE Product type: Data connector (device side) Sensor type: Single Pair Ethernet Number of positions: 2 Type of packaging: Tape and Reel Pitch: 7.62 mm Connection profile: SPE Number of slots: 1 Shielded: yes Cable outlet: straight LED: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 VÃDC Rated surge voltage: 2250 VÃDC Rated surge voltage (III/2): 1500 V Rated current: 4 A Frequency range: 600 MHz Insulation resistance: > 1 Té Transmission medium: Copper Transmission speed: 1 Gbps Power transmission: PoDL |
| Connection data | Connection technology Connection method: THR solder connection |
| Dimensions | Width: 7.52 mm Height: 13.33 mm Length: 20.6 mm |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Ni/Au Contact carrier material: LCP Housing material: Plastic |
| Cable/line | Test voltage Core/Core: 1000 VÃDC Test voltage Core/Shield: 2250 VÃDC Resistance to oil: yes Flame resistance: ULÃ94 V0 |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 750 Insertion force per signal contact: < 1.50 N Extraction force per signal contact: < 1.5 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C Resistance to oil: yes |
| Standards and regulations | Flame resistance: ULÃ94 V0 Resistance to oil: yes |
| Mounting | Mounting type: THR soldering Connection method: THR solder connection Processing notes Moisture Sensitive Level: MSL 1 |
