| Product properties | Type: RJ45 Socket Product type: Data connector (device side) Number of positions: 8 Type of packaging: Tape and Reel [W] tape width: 44.00 mm [A] coil diameter: 330.00 mm [W2] coil overall dimension: 50.40 mm Connection profile: RJ45 Number of slots: 1 Shielded: yes LED: yes Insulation characteristics Overvoltage category: II Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 VÃDC Rated surge voltage: 1.5 kV DC 1 kV DC Rated surge voltage (III/3): 1.5 kV Rated current: 1.5 A Frequency range: 10 Hz ... 500 Hz Insulation resistance: > 500 Mé Test voltage: 1 kV DC Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Transmission medium: Copper Transmission speed: 10 Gbps Power transmission: PoE++ |
| Connection data | Connection technology Connection method: THR solder connection |
| Dimensions | Width: 16.1 mm Height: 14.7 mm Length: 17.5 mm Installed height: 14.30 mm Orientation to: 180.00° Data pin length: 2.00 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: Nickel Contact material: Copper alloy Contact surface material: Gold Housing material: Metal |
| Cable/line | Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Halogen-free: yes |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 105°C Ambient temperature (storage/transport): -40°C ... 105°C |
| Mounting | Mounting type: THR soldering Connection method: THR solder connection |
