| Notes | General: This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.2 Connectors for Outside Environment (Balanced cabling) and chapter 13 Application specific Cabling and Interconnection Technology (AIDA) |
| Product properties | Type: SC-RJ Product type: Panel mounting frame Number of positions: 2 Connection profile: SC-RJ Application: Freenet system Cable outlet: straight Insulation characteristics Degree of pollution: 2 |
| Electrical properties | Transmission medium: FO |
| Connection data | Connection technology Connection method: Push-Pull |
| Dimensions | Mechanical characteristics Ferrule diameter: 2.50 mm |
| Material specifications | Color: silver Material: Metal Flammability rating according to UL 94: V0 Housing surface material: nickel-plated Housing material: Metal |
| Cable/line | Resistance to oil: yes Flame resistance: yes FO cable Number of fibers: 2 Fiber: POF, PCF, GOF Fiber type: GOF, PCF, POF Transmission medium: FO |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: = 100 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 (IP65/67) IP65/IP67 Ambient temperature (operation): -40°C ... 70°C Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): 0°C ... 50°C Resistance to oil: yes |
| Standards and regulations | Flame resistance: yes Resistance to oil: yes |
| Mounting | Mounting type: Wall mounting Connection method: Push-Pull |
