1658493 PHOENIX CONTACT -

VS-08-RJ45-5-Q/IP67-BK - RJ45 connector

RJ45 connector, design: RJ45, degree of protection: IP67, number of positions: 8, 1 Gbps, CAT5, material: Plastic, connection method: IDC fast connection, connection cross section: AWG 26- 23, cable outlet: straight, color: jet black RAL 9005, Ethernet

Cod. Articolo: 1658493 copia - copy

Cod. Fornitore: 1658493 copia - copy

PHOENIX CONTACT

Product properties	Type: RJ45 Product type: Data connector (cable side) Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 No. of cable outlets: 1 Shielded: yes Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2
Electrical properties	Rated voltage (III/3): 72 V (DC) Rated current: 1.75 A Nominal voltage U_N: 48 V Contact resistance: 0.001 Ã© (Wire Ã¢Ã¢¬Ã¢ IDC) 0.005 Ã© (Litz wires Ã¢Ã¢¬Ã¢ IDC) Transmission medium: Copper Transmission characteristics (category): CAT5 Transmission speed: 1 Gbps Power transmission: PoE++
Connection data	Connection technology Connection method: IDC fast connection Connection cross section AWG: 26 ... 23 (solid) 26 ... 23 (flexible) Conductor cross section: 0.14 mm² ... 0.36 mm² (solid) 0.14 mm² ... 0.36 mm² (flexible)
Dimensions	Width: 38.4 mm Height: 22.4 mm Length: 80 mm
Material specifications	Color: jet black RAL 9005 Material: Plastic Flammability rating according to UL 94: V0 Cable seal material: NBR Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: PC O-ring material: FPM Housing material: Plastic
Cable/line	External cable diameter (): 5 mm ... 8.5 mm Cable cross section: 0.14 mm²
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 1000
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 55°C
Mounting	Connection method: IDC fast connection
