2764153 PHOENIX CONTACT -

EG 45-GP/ABS GN - Mounting base housing

Component housing, Lower housing part, with snap-on foot and test opening with side cover, without vents, width: 45 mm, height: 75 mm, color: green (6021), cross connection: without bus connector, number of positions cross connector: not relevant

Cod. Articolo: 2764153 copia - copy

Cod. Fornitore: 2764153 copia - copy

PHOENIX CONTACT

Product properties	Type: Lower housing parts with test opening with side cover, housing cover necessary to complete the module Lower housing part, with snap-on foot and test opening with side cover Product type: Enclosure bottom part Product family: EG Number of positions: 16 Housing type: Component housing Ventilation openings present: no Housing series: EG
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fdd7f57abcbd3549ae1e3573c4fc7dee/-S204x204-FJPG Width: 45 mm Height: 75 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm
Material specifications	Color: green (6021) Flammability rating according to UL 94: HB Surface characteristics: untreated Housing material: ABS
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 80°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 80°C
PCB data	Thickness of the PCB: 1.4 mm ... 1.8 mm
Mounting	Mounting type: DIN rail mounting Mounting position: Vertical (horizontal DIN rail)
