| Product properties | Type: FSMA Product type: Data connector (cable side) Number of positions: 2 Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Attenuation: < 1.5 dB (Insertion attenuation) Transmission medium: FO Transmission characteristics (category): MM |
| Material specifications | Flammability rating according to UL 94: V0 Housing material: Metal |
| Cable/line | Cable type: Plastic-coated fiber External cable diameter (): 2.2 mm ... 2.2 mm Individual wire diameter: 2.2 mm Resistance to oil: yes Flame resistance: yes FO cable Fiber: 980/1000Ãõm Fiber type: POF |
| Characteristics | Attenuation: < 1.5 dB (Insertion attenuation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 80°C Ambient temperature (storage/transport): -40°C ... 80°C Ambient temperature (assembly): 0°C ... 50°C Resistance to oil: yes |
| Standards and regulations | Flame resistance: yes Resistance to oil: yes |
| Mounting | Mounting type: For field assembly |
