| Notes | General: Ferrules are not included in DIN 46228-4: 1990-09 |
| Product properties | Product type: Cable end sleeve |
| Connection data | Conductor connection Conductor cross section flexible max.: 70 mm² Conductor cross section AWG max.: 2 Stripping length: 25 mm |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/9aff783b62b3954eb89dadb60aec1582/-S204x204-FJPG Sleeve length: 20 mm Maximum stripping length: 25 mm Ferrule diameter: 12.7 mm Sleeve wall thickness: 0.35 mm Insulating collar thickness: 0.6 mm Inner dimensions of the insulating collar: 16 mm |
| Material specifications | Color: yellow Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen |
| Mechanical properties | Technical data Sleeve length: 20 mm |
| Environmental and real-life conditions | Ambient conditions Permanent temperature: 105°C (-40ðC no load / 0ðC dynamic load) Short-term temperature: 120°C |
