| Mounting | Mounting type: Screw mounting |
| Product properties | Type: M12 Product type: Circular connectors (device side) Sensor type: Ethernet Number of positions: 8 Number of slots: 1 Shielded: yes Coding: X Cable outlet: straight Insulation characteristics Degree of pollution: 3 |
| Material specifications | Material: Zinc die-cast (nickel-plated) Flammability rating according to UL 94: V2 Seal material: FKM Material of grip body: Zinc die-cast, nickel-plated Contact material: CuZn Contact surface material: gold-plated Contact carrier material: PPA Material for screw connection: Zinc die-cast, nickel-plated Outer sheath, material: PUR |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Nominal voltage UN: 48 V Nominal current IN: 0.5 A Transmission medium: Copper Transmission characteristics (category): CAT6A Transmission speed: 10 Gbps |
| Connector | Connection 1 Type: Flush-type female connector straight M12 Coding type: X (Data) Degree of protection: IP67 Number of positions: 8 Locking type: SPEEDCON Connection 2 Type: Plug straight RJ45 Number of positions: 8 Degree of protection: IP20 |
| Cable/line | Cable length: 1.00 m Ethernet 10 GbitÃ[94F] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/0314c1656ba7d3438a5ae0749b98c42e/-S204x204-FJPG Shielded: yes UL AWM Style: 20963 (80°C/30 V) Cable weight: 42 kg/km Cable type: Ethernet 10 Gbit Short symbol: 02YSC11Y Cable type (abbreviation): 94F Signal type/category: Ethernet CAT6A, 10 Gbps Cable structure: 4x2xAWG26/7; S/FTP External cable diameter: 6.4 mm ñ0.2Ãmm Outer sheath, material: PUR External sheath, color: water blue RALÃ5021 Thickness, outer sheath: 0.65 mm Conductor material: Bare Cu litz wires Conductor structure signal line: 7x 0.16 mm AWG signal line: 26 Conductor cross section: 4x 2x 0.14 mm² Material wire insulation: Foamed PE Wire diameter incl. insulation: 1.04 mm Single wire, color: white/blue-blue, white/orange-orange, white/green-green, white/brown-brown Twisted pairs: 2 cores to the pair Type of pair shielding: Aluminum-lined foil Overall twist: 4 pairs for core Shielding: Tinned copper braided shield Optical shield covering: 70 % Nominal voltage, cable: ââ°¤ 100 V Test voltage Core/Core: 700 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 700 V (50ÃHz, 1Ãmin.) Cable insulation resistance: ââ°¥ 500 Mé*km Wave impedance: 100 é ñ5Ãé (at 100 MHz) Loop resistance: ââ°¤ 290.00 é/km Cable capacity: 47 nF/km Signal runtime: 5.13 ns/m Tensile strength: ââ°¤ 100 N Minimum bending radius, fixed installation: 4 x D Minimum bending radius, flexible installation: 8 x D Damping: 3.1 dB (with 1 MHz) 5.7 dB (at 4 Ãà Hz) 8 dB (at 8ÃÃà Hz) 8.9 dB (at 10 MHz) 11.2 dB (at 16 MHz) 12.6 dB (at 20ÃÃà Hz) 14.1 dB (at 25ÃMHz) 15.8 dB (at 31.25ÃÃà Hz) 22.5 dB (at 62.5ÃÃà Hz) 28.7 dB (at 100 MHz) 41.4 dB (at 200 MHz) 46.6 dB (at 250ÃMHz) 51.4 dB (at 300ÃMHz) 60.1 dB (at 400ÃMHz) 67.9 dB (at 500ÃMHz) Near end crosstalk attenuation (NEXT): 75.3 dB (with 1 MHz) 66.3 dB (at 4 Ãà Hz) 61.8 dB (at 8ÃÃà Hz) 60.3 dB (at 10 MHz) 57.2 dB (at 16 MHz) 55.8 dB (at 20ÃÃà Hz) 54.3 dB (at 25ÃMHz) 52.8 dB (at 31.25ÃÃà Hz) 48.4 dB (at 62.5ÃÃà Hz) 45.3 dB (at 100 MHz) 40.8 dB (at 200 MHz) 39.3 dB (at 250ÃMHz) 38.1 dB (at 300ÃMHz) 38.1 dB (at 400ÃMHz) 38.1 dB (at 500ÃMHz) Power-summated near end crosstalk attenuation (PSNEXT): 72.3 dB (with 1 MHz) 63.3 dB (at 4 Ãà Hz) 58.8 dB (at 8ÃÃà Hz) 57.3 dB (at 10 MHz) 54.2 dB (at 16 MHz) 52.8 dB (at 20ÃÃà Hz) 51.3 dB (at 25ÃMHz) 49.9 dB (at 31.25ÃÃà Hz) 45.4 dB (at 62.5ÃÃà Hz) 42.3 dB (at 100 MHz) 37.8 dB (at 200 MHz) 36.3 dB (at 250ÃMHz) 35.1 dB (at 300ÃMHz) 33.3 dB (at 400ÃMHz) 31.8 dB (at 500ÃMHz) Return attenuation (RL): 20 dB (with 1 MHz) 23 dB (at 4 Ãà Hz) 24.5 dB (at 8ÃÃà Hz) 25 dB (at 10 MHz) 25 dB (at 16 MHz) 25 dB (at 20ÃÃà Hz) 24.2 dB (at 25ÃMHz) 23.3 dB (at 31.25ÃÃà Hz) 20.7 dB (at 62.5ÃÃà Hz) 19 dB (at 100 MHz) 16.4 dB (at 200 MHz) 15.6 dB (at 250ÃMHz) 15.6 dB (at 300ÃMHz) 15.6 dB (at 400ÃMHz) 15.6 dB (at 500ÃMHz) Shield attenuation: ââ°¥ 80 dB (at 30 ... 100 MHz) Halogen-free: according to IEC 60754-1 Resistance to oil: in accordance with DINÃENÃ60811-2-1 Flame resistance: according to IEC 60332-1-2 Ambient temperature (operation): -20°C ... 80°C (Cable, flexible installation) -40°C ... 80°C (cable, fixed installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 (M12 socket) IP20 (RJ45 connector) IP67/IP20 Ambient temperature (operation): -25°C ... 60°C (Plug / socket) |
